- Schott substrate material
- Thickness 2.0mm
- Surface Quality: 60/40 (Refer to MIL-O-13830)
- Fine-optically polished to ensure accurate 1/4 wavefront and <30 seconds parallelism over the both surfaces
- 95% transmission at passband
- Infrared wavelength 700-1100nm cut-off
- Precision off-band blocking
- Multi-layers anti-reflection coating
- Non-cementing optical substrate coating
- Electron-beam gun evaporation with Ion-assisted deposition coating technology for durability and resistance to scratching, as well as stability on CWL (central wavelength) no deviation affected by temperature change
- Planetary rotation system offers precision and homogeneity of coatings ensuring high value on transmission of pass-band and Optical density of off-band
- Ultra-thin filter cell minimize vignetting by maximize possible clear aperture. Clear aperture is 26mm.
- Aerometal Material
This item is normally shipped by Courier.
